Troubleshooting Your Industrial Vacuum Pump: Common Problems and Solutions

Industrial vacuum pumps play a vital role in production processes. They are typically used to remove air, gases or vapours and to create vacuum environments for various industrial applications. However, like any mechanical system, vacuum pumps can experience malfunctions; these can disrupt production and cause time loss. In this article we examine the common problems of industrial vacuum pumps, their possible causes and solutions.

Note: Some of the checks below vary by pump type (oil-lubricated rotary vane, liquid ring or dry type). Before any intervention, switch off the pump's power and let it cool, because of hot surfaces and oil; have electrical and mechanical work carried out by authorised personnel.

Vacuum Pump Not Running or Starting

A vacuum pump that does not run is one of the common issues encountered in industrial systems. When faced with this problem, the first step is to identify the source of the malfunction. A pump that does not run at all can be caused by the following:

Electrical Failures: Most vacuum pumps operate electrically. A power outage, blown fuse, broken wire or tripped circuit breaker can stop the pump. First check the supply voltage; make sure the wires are intact, the fuses have not blown and power is reaching the pump.
Motor Failure: If the motor is faulty, the pump will not run. Authorised electrical personnel can test the motor with a multimeter and suitable measuring instruments. Also check whether the motor is overheating and whether the protection circuit has tripped.
Insufficient Power Supply: The supply voltage and current capacity must be sufficient for the pump to operate. If the supply does not match the voltage and frequency on the pump's nameplate, the pump may not run. In this case the supply line and voltage values should be checked and, if necessary, the line brought into compliance.
Control Panel or Thermal Protection Failure: The control panel or thermal protection system can fail. Thermal protection trips to prevent the motor from overheating; if it trips frequently, the cause should be investigated. If the thermal protection has been disabled, the motor may be prevented from running.

For such failures, the intervention of an authorised technician may be needed. Regular maintenance and electrical checks help detect problems in advance.

Low Vacuum Pressure

A low vacuum level is an important problem that directly affects pump performance. The pump failing to reach the target ultimate pressure (mbar), or taking longer to reach it, can be caused by the following:

Leaking Connections: A leaking connection in the vacuum system causes the pressure to rise (the vacuum to deteriorate). Leaks are especially common at hose connections and flanges. Make sure all connections are sound and renew gaskets or sealing materials if necessary.
Dirty or Clogged Filters: Filters can become dirty and clogged over time; this restricts flow in the suction line and lowers pump efficiency. Check filters regularly and clean or replace them when necessary.
Valve and Line Problems: Valves left in the wrong position or not closing fully, damaged line components and leaks in discharge or venting lines can lower the vacuum level. Check the valves, lines and equipment connected to the system one by one.
Wear, Oil or Operating Liquid Condition: On rotary vane pumps, worn vanes or dirty or insufficient oil, and on liquid ring pumps insufficient or too-warm operating water, can lower the vacuum level. Check the level and condition of the oil or operating liquid; if the problem persists, contact authorised service.
Incorrect Settings: For the pump to reach the right vacuum level, the system must operate with the correct parameters. Review settings such as operating pressure and, where fitted, gas ballast against the values recommended by the manufacturer.

Resolving these problems keeps the vacuum system running efficiently and helps extend pump life. Regular maintenance and system tests allow problems to be noticed early.

Apply Now

Vacuum Pump Overheating

Overheating is a problem that prevents the pump from running efficiently for long periods. Common causes are:

Lack of Oil or Oil Contamination: On oil-lubricated (rotary vane) vacuum pumps, the oil lubricates the moving parts, helps sealing and carries heat away. Low or contaminated oil can increase friction and lead to overheating. Check the oil level regularly and change the oil when necessary.
Insufficient Cooling: The cooling system (air or water) must work properly. If airflow around the pump is insufficient, or the cooling water flow or temperature is unsuitable, the pump may overheat. Check the cooling system and anything blocking airflow. On liquid ring pumps, the temperature and flow of the operating water should also be monitored.
Unsuitable Duty Pattern: The permitted duty pattern of industrial vacuum pumps varies with the model and application. Running the pump for long periods at high suction pressure (far from vacuum) or exceeding the duty pattern specified by the manufacturer can cause overheating. Compare your operating conditions with the values specified by the manufacturer.
Wrong Oil Type: An oil different from the one recommended for the pump can increase friction and reduce heat dissipation. Use the oil type recommended by the manufacturer.

Overheating leads to inefficient operation of the motor and the pump. Regular maintenance and timely oil changes can reduce the risk of overheating.

Vacuum Pump Making Loud Noises or Rattling

Noisy operation can indicate that the pump is not working correctly. If the pump makes more noise than normal, there may be several causes:

Foreign Objects: Foreign objects entering the pump can cause rattling noises. Using a filter and separator on the suction line reduces the entry of foreign matter. If the inside of the pump needs to be opened and cleaned, have this done by authorised service.
Faulty Parts: If bearings, vanes, the coupling or other moving parts are damaged, rattling or noise may be heard. In this case the damaged parts must be replaced; get support from authorised service for mechanical inspection and parts replacement.
Lack of Lubrication: On oil-lubricated pumps, insufficient lubrication increases friction between parts and raises the noise. Check the oil level and ensure adequate lubrication; a lubrication problem can cause overheating as well as excessive noise.
Cavitation: On liquid ring pumps, if the operating water is too warm or the inlet conditions are unsuitable, a noise similar to gravel rattling can occur because of cavitation. Check the operating water temperature and flow.

When abnormal noise is noticed, not running the pump for long periods prevents possible mechanical damage from growing.

Vacuum Pump Leaking Oil

Oil leakage is a problem seen on oil-lubricated vacuum pumps, usually arising when maintenance is neglected. Leaks can affect proper pump operation and pollute the environment. The main causes are:

Seal Wear: Seals in the pump can wear over time and cause oil leakage. Check the seals regularly and replace them when necessary.
Excessive Oil Level: When the oil level is too high, oil can leak out through seals or vent points. Keep the oil level within the range recommended by the manufacturer.
Oil Cooling Problems: If the oil cooling arrangement is not working properly, the temperature rises, the oil thins and the risk of leakage increases. Check the cooling arrangement and make sure it is adequate.

Oil leaks affect not only equipment efficiency but also the environment. It is therefore important to act quickly when a leak is noticed.

If the problem is not solved by these checks, or you cannot determine its cause, note the pump model and the fault symptoms and contact the Gücüm Pompa service team.
